Specifications:

• Suitable for charging under pressure of max 5500 mm H2O.
• Total capacity 650 lt.
• Working capacity 325 lt.
• Fixed speed 70 rpm

The mixer consists of:

• A container made up by two shaped tanks “V” type connected
• All parts in contact with the product are made of stainless steel AISI 316
• Other parts made of Steel.
• Charging opening Ø 400 mm at the top of the tanks.
• Discharge opening at the base of the “V” Ø 200 mm butterfly valve
• Reduction gear motor HP 5.3 V.380 Hz.50 IP 55
• Bearing structure in sheet and carbon steel profiles
• Front protecting bar equipped with safety limit switch
• The body of the mixer rotates on two supporting units with swinging bearings
